HIKMICRO Condor CQ50L 2.0 LRF Thermal Imaging Monocular

The HIKMICRO Condor CQ50L 2.0 is a premium long-range 640 thermal imaging monocular with integrated laser rangefinder, designed for users who require exceptional thermal detail, greater magnification and outstanding detection performance.

Featuring a high-resolution 640×512 12µm thermal sensor with <15mK NETD, a fast 50mm F0.9 germanium objective lens and HIKMICRO’s advanced image-processing technology, the CQ50L 2.0 delivers excellent image detail even in challenging, low-thermal-contrast conditions.

With an integrated 1000m laser rangefinder, 2.7–21.6× magnification and manufacturer-stated detection range of up to 2600 metres, the Condor CQ50L 2.0 is particularly well suited to longer-range wildlife observation, gamekeeping, pest control, land management and professional field use.

High-Resolution 640×512 Thermal Sensor

At the heart of the Condor CQ50L 2.0 is a high-resolution 640×512 VOx thermal sensor with a 12µm pixel pitch.

Its excellent <15mK NETD thermal sensitivity allows the monocular to distinguish very small differences in temperature, helping reveal finer details in both the target and surrounding landscape.

This is particularly useful in difficult conditions such as mist, damp weather, high humidity and colder environments where there may be relatively little temperature difference between an animal and its surroundings.

A 50Hz frame rate provides smooth thermal imaging when scanning or observing moving heat sources.

Powerful 50mm F0.9 Objective Lens

The CQ50L 2.0 uses a fast 50mm F0.9 germanium objective lens, providing increased optical magnification and excellent long-range detection capability.

The large F0.9 aperture allows more infrared energy to reach the thermal detector, complementing the highly sensitive <15mK sensor.

With 2.7× base magnification, the CQ50L is particularly well suited to customers who regularly observe across larger fields and open countryside.

Up to 2600m Thermal Detection

The combination of the 640×512 sensor and 50mm F0.9 lens provides a manufacturer-stated detection range of up to 2600 metres.

This makes the CQ50L 2.0 an excellent choice for long-range thermal scanning and observation.

Actual detection and identification distances will vary according to target size, weather, vegetation, atmospheric conditions and the surrounding environment.

Detection range should therefore not be confused with identification distance.

Integrated 1000m Laser Rangefinder

The HIKMICRO Condor CQ50L 2.0 features an integrated laser rangefinder (LRF) capable of measuring distances out to a manufacturer-stated 1000 metres.

With stated accuracy of approximately ±1 metre under specified conditions, the LRF provides useful distance information directly through the thermal monocular.

Accurately judging distance from a thermal image alone can be difficult, particularly at night and across open countryside, making an integrated LRF a valuable feature for gamekeeping, wildlife observation and pest-control applications.

2.7–21.6× Magnification

The CQ50L 2.0 provides 2.7× base magnification, with digital magnification extending the viewing range up to 21.6×.

This higher base magnification is one of the important differences between the CQ50L and the CQ35L.

The CQ50L is therefore particularly well suited to users who prioritise longer-range observation and greater target detail over an exceptionally wide scanning view.

8.7° Field of View

The 50mm objective provides an 8.7° × 7.0° field of view, equivalent to approximately 15.2m × 12.2m at 100 metres.

This narrower field of view works particularly well for examining heat sources at longer distances.

For customers who primarily require a wider view for relatively close-range scanning, the Condor CQ35L 2.0 may be more appropriate.

HIKMICRO Shutterless Image System – HSIS

The Condor 2.0 series features HIKMICRO’s Shutterless Image System (HSIS).

Conventional thermal imagers periodically calibrate the image using a shutter, which can momentarily interrupt observation.

HSIS is designed to provide a smoother, more continuous thermal image with fewer interruptions, making observation more natural when scanning or following moving wildlife.

Advanced Image Processing

The CQ50L 2.0 incorporates HIKMICRO’s advanced image-processing technologies to maximise the performance of its high-sensitivity thermal detector.

These include Image Pro and Zoom Pro, which are designed to enhance image detail and maintain useful image quality when digital magnification is increased.

Combined with the <15mK sensor and F0.9 lens, these technologies help produce a detailed thermal image across a wide variety of conditions.

1920×1080 OLED Display

The thermal image is presented through a large 0.49-inch 1920×1080 OLED display.

The high-resolution display complements the 640×512 thermal detector and provides a detailed viewing experience when observing for extended periods.

Available thermal palettes include:

• White Hot
• Black Hot
• Red Hot
• Fusion
• Red Monochrome
• Green Monochrome

This allows the display to be configured to suit different environments and personal viewing preferences.

Built-In Photo & Video Recording

The HIKMICRO Condor CQ50L 2.0 includes 64GB of built-in storage.

Thermal photographs and video can therefore be captured directly through the monocular without requiring a separate recording device.

Audio recording is also supported, allowing commentary and environmental sound to be captured alongside video where required.

Dual-Band Wi-Fi

Built-in 2.4GHz and 5GHz Wi-Fi allows the CQ50L 2.0 to connect wirelessly to compatible smartphones and tablets.

This provides access to supported HIKMICRO app functions and makes it easier to view and manage captured thermal images and video.

Replaceable 21700 Battery

Power is provided by a replaceable and rechargeable 21700 lithium-ion battery.

HIKMICRO states operating time of at least approximately 6.5 hours at 25°C with Wi-Fi, Zoom Pro and LRF switched on.

The replaceable battery design allows a spare charged battery to be carried for longer periods in the field.

USB Type-C supports direct charging and external power.

Rugged IP67 Construction

The CQ50L 2.0 carries an IP67 protection rating, providing protection against dust and water for demanding outdoor use.

Its manufacturer-stated operating temperature range extends from approximately -30°C to +55°C, making it suitable for year-round field observation.

Despite its 50mm objective lens, 640 sensor and integrated LRF, the unit weighs approximately 537g including the battery.

Ideal for Long-Range Wildlife, Gamekeeping & Pest Control

The CQ50L 2.0 is particularly suited to situations where longer detection distance and greater base magnification are more important than maximum field of view.

Typical applications include:

• Wildlife observation
• Gamekeeping
• Pest control
• Land and estate management
• Long-range field scanning
• Open countryside observation
• Night-time observation
• Locating and ranging animals and other heat sources
• Professional thermal observation

For pest-control and gamekeeping applications, the combination of 2.7× base magnification, 2600m stated detection and integrated 1000m LRF makes the CQ50L particularly useful across larger fields and open ground.

Key Features

• Premium HIKMICRO Condor 2.0 thermal monocular
• 640×512 thermal sensor
• 12µm pixel pitch
• Excellent <15mK NETD
• 50Hz frame rate
• Fast 50mm F0.9 objective lens
• 2.7–21.6× magnification
• 8× digital zoom
• 8.7° × 7.0° field of view
• 15.2m × 12.2m FOV at 100m
• Up to 2600m manufacturer-stated detection range
• Integrated 1000m laser rangefinder
• ±1m stated LRF accuracy
• HIKMICRO Shutterless Image System
• Advanced image processing
• Zoom Pro
• 1920×1080 OLED display
• Six thermal colour palettes
• Built-in photo and video recording
• Audio recording
• 64GB internal storage
• 2.4GHz / 5GHz Wi-Fi
• Replaceable rechargeable 21700 battery
• ≥6.5 hours manufacturer-stated operation
• USB Type-C
• IP67 protection
• Approximately 537g including battery

Technical Specification

Model: HIKMICRO Condor CQ50L 2.0
Thermal Sensor: 640×512 VOx
Pixel Pitch: 12µm
NETD: <15mK
Frame Rate: 50Hz
Objective Lens: 50mm F0.9
Minimum Focusing Distance: 5m
Magnification: 2.7–21.6×
Digital Zoom: Up to 8×
Field of View: 8.7° × 7.0°
FOV at 100m: 15.2m × 12.2m
Detection Range: Up to 2600m
Laser Rangefinder: Yes
LRF Range: Up to 1000m
LRF Accuracy: ±1m under specified conditions
Minimum LRF Range: 10m
Display: 0.49-inch 1920×1080 OLED
Internal Storage: 64GB
Photo & Video Recording: Yes
Audio Recording: Yes
Wi-Fi: 2.4GHz / 5GHz
Battery: Replaceable rechargeable 21700
Operating Time: ≥6.5 hours under manufacturer’s stated conditions
Charging: USB Type-C
Protection Rating: IP67
Operating Temperature: -30°C to +55°C
Dimensions: 193 × 71.5 × 93.3mm
Weight: Approximately 537g including battery

Why Choose the HIKMICRO Condor CQ50L 2.0?

The HIKMICRO Condor CQ50L 2.0 is particularly well suited to customers looking for a premium long-range 640 thermal monocular with integrated LRF.

The combination of a 50mm F0.9 lens and 2.7× base magnification provides greater reach than the CQ35L 2.0, while the highly sensitive 640×512 <15mK sensor delivers excellent thermal detail.

Add the 2600m stated detection range, 1000m laser rangefinder, HSIS and high-resolution OLED display, and the CQ50L 2.0 becomes an extremely capable thermal spotter for larger fields and longer-distance observation.

HIKMICRO Condor CQ50L 2.0 from Ellmor

The HIKMICRO Condor CQ50L 2.0 LRF Thermal Imaging Monocular combines excellent thermal sensitivity with long-range optics and accurate laser rangefinding.

For wildlife observation, gamekeeping, pest control and professional field use, its combination of a 640×512 sensor, 50mm F0.9 lens, <15mK sensitivity, 2600m stated detection and 1000m LRF makes the CQ50L 2.0 an excellent premium long-range thermal monocular.
