Description

Neos NH35L LRF Overview
The HikMicro Neos NH35L LRF sits at the upper end of the Neos thermal riflescope series, using a 384×288 VOx thermal sensor paired with a 35mm F1.0 objective lens. Compared with the 25mm Neos models, the NH35L is configured around extended detection capability, narrower field of view and integrated ballistic support.

The thermal module uses a 12μm pixel pitch sensor with sub-18mK NETD sensitivity and a 50Hz refresh rate. HikMicros’s HSIS shutterless system is combined with Image Pro 3.0 and Zoom Pro processing to reduce image interruption while improving perceived detail and target separation in lower thermal contrast conditions.

A 0.49-inch AMOLED display is used for image output, supporting multiple colour palettes and display adjustments. The NH35L also incorporates Sync Pro integration and Quick Zeroing through the Sight application.

Optical Configuration
The Neos NH35L uses a 35mm F1.0 germanium objective lens with a quoted magnification range of 3.2× to 25.6×. Detection range is specified at 1800m, positioning the scope for longer-range observation and engagement compared with shorter focal length Neos configurations.

Field of view is quoted at 7.6° × 5.7°, equivalent to 13.1m × 10.0m at 100m. Minimum focusing distance is specified at 3m.

The display system includes brightness adjustment, contrast adjustment and selectable warm or cold tone settings. Exit pupil is specified at 8mm with 55mm eye relief and diopter adjustment from -4D to 4D.

Laser Rangefinder and Ballistics
The integrated laser rangefinder provides a maximum measuring range of 1000m with ±1m stated accuracy and a minimum measuring range of 10m. The system uses a Class 1 905nm laser.

Unlike the lower Neos configurations, the NH35L also incorporates onboard ballistic calculation functionality. Distance measurement and ballistic correction are integrated directly within the riflescope platform rather than requiring external calculation devices.

Recording and System Functions
The Neos NH35L supports onboard video recording, audio recording, snapshot capture and recoil-activated recording. Internal storage capacity is specified at 64GB EMMC.

Five separate zeroing profiles are supported, alongside freeze zeroing, Picture-in-Picture mode and local album functionality.

Maximum recoil resistance is rated at 1000g/0.4ms.

Power and Physical Design
The scope uses a combined internal rechargeable battery and external replaceable 18650 battery system. Operating time is specified at up to 8 hours continuous use at 25°C with Zoom Pro and LRF enabled.

The housing is IP67 rated and built around a standard 30mm mounting platform. Total dimensions are quoted at 345.6mm × 86.1mm × 75.8mm with a total weight of 570g.

• Specification HIKMICRO Neos NH35L LRF
  Sensor 384 × 288 VOx, 12μm
  NETD <18mK
  Lens 35mm F1.0
  Magnification 3.2× – 25.6×
  Detection Range 1800m
  Field of View 7.6° × 5.7° / 13.1m × 10.0m @100m
  Display 0.49-inch AMOLED
  Frame Rate 50Hz
  Laser Rangefinder 1000m, ±1m accuracy
  Ballistic Calculation Yes
  Recording Video, audio, recoil-activated
  Storage 64GB EMMC
  Zeroing Profiles 5
  Battery Life Up to 8 hours
  Protection IP67
  Mount 30mm tube
  Weight 570g
